Betonganläggning ny Constmach 300 Ton Capacity Cement Silo

You can call us 24/7 for a 300 ton cement silo for sale

Our CS-300 model is a cement silo that attracts attention with its capacity. the storage capacity of 300 tons provides an ideal solution for high-volume projects. the silo, which has a height of 18450 mm and a diameter of Ø 5140 mm, is supported by 6 solid legs. These legs are made of Ø273 x 10 mm steel pipe and are reinforced with NPL 80 mm corner irons.

The silo body and other components are made of ST-37 metal sheets, which guarantees durability and longevity. the structure, consisting of 191 parts, is the result of a detailed engineering and production process. the tapered part, supported by 20 mm thick foot plates and 200 mm steel C channel, provides stability and safety.

Features of the CS-300, such as an external manhole and an internal manhole, offer ease of maintenance and operation. The silo roof comes with arrests and the maintenance platform is available. The high-quality painting process is completed with 1 layer of anticorrosive paint and 2 layers of top coat epoxy paint, providing protection with a total thickness of 140 microns.

If you are looking for high performance and reliability in your projects, our CS-300 model is for you. With its robust structure, large storage capacity and superior material quality, it meets your expectations even in the most demanding conditions. This silo, every detail of which has been carefully designed, will facilitate your business processes and increase your productivity.

Technical Specifications of CS-300 - 300 Ton Cement Silo

Silo Capacity is 300 tons, 230 m3 (cement density is 1.3 tons/m3)
Silo Height 18450 mm
Silo Diameter Ø 5140 mm
The Number of Silo Feet is 6
Silo Outlet Diameter Ø 300 mm
Number of Components 191
Silo Weight 22000 kg
Silo Foot Material Ø273 x 10 mm steel pipe
Silo Foot Supports NPL 80 mm corner iron
Silo Foot Plates 20 mm
Taper Part Support Material 200 mm steel c channel
Conical Part Material ST-37, 8 mm metal sheet
Silo Body Material ST-37, 8 - 6 - 5 mm metal sheet
Silo Top Cover Material ST-37, 5 mm metal sheet
Charging Pipe 4" steel pipe up to the silo leg
Internal Manhole is available
External Man Hole is available
The Silo Roof is included in the arrests
The Maintenance Platform is available
Structure Analysis is carried out for silos and the production process is carried out depending on the approved projects
Painting 1 layer of anticorrosive paint, 2 layers of top coat epoxy paint, total paint thickness 140 microns
